| 驱动器型号 | 电气参数 | 结构参数 | ||||||||
| 电源容量 | 输入电流 | 输出电流 | 适配电机 | 外形尺寸 | 安装尺寸 | 包装尺寸 | 总重 | |||
| KVA | A | A | KW | HP | H*W*D/mm | H1*W1/mm | H2*W2*D2/cm | KG | ||
| 过载：G型150%1分钟180%2秒 最高输出频率：异步电机600HZ/同步电机500ZH | ||||||||||
| 三相输入：额定AC380V(适应工作范围380～460±15%)50/60HZ(±5%) | ||||||||||
| MK500-4T1.5GB-MF | 5 | 4.6 | 3.8 | 1.5 | 2 | 6.3 | ||||
| MK500-4T2.2GB-MF | 6.7 | 6.3 | 5.1 | 2.2 | 3 | 295*200*194 | 正面278*130侧 面275*100 φ7*4 | 412*267*267 | 6.3 | |
| MK500-4T4.0GB-MF | 6.2 | 11.5 | 9 | 4 | 5 | 6.4 | ||||
| MK500-4T5.5GB-MF | 17.5 | 16.7 | 13 | 5.5 | 7.5 | 6.4 | ||||
| MK500-4T7.5GB-MF | 22.8 | 21.5 | 17 | 7.5 | 10 | 10.8 | ||||
| MK500-4T11GB-MF | 33.4 | 32.2 | 25 | 11 | 15 | 正面416.7*190 | 11 | |||
| MK500-4T15GB-MF | 42.8 | 41.3 | 32 | 15 | 20 | 427*243*218 | 侧面400*100中 | 502*332*307 | 11.5 | |
| MK500-4T18GB-MF | 45 | 49.5 | 37 | 18.5 | 25 | 7*4 | 11.7 | |||
| MK500-4T22GB-MF | 54 | 59 | 45 | 22 | 30 | 12 | ||||
| MK500-4T30GB-MF | 61 | 57 | 63 | 30 | 40 | 455*283*230 | 443.2*200φ6.5 | 51*36*32 | 17.5 | |
| MK500-4T37G-MF | 65 | 69 | 75 | 37 | 50 | 18.5 | ||||
| MK500-4T45G-MF | 81 | 88 | 90 | 45 | 60 | 30.5 | ||||
| MK500-4T55G-MF | 97 | 105 | 110 | 55 | 70 | 510*340*280 | 495*270φ8 | 64*45*39 | 30 | |
| MK500-4T75G-MF | 128 | 141 | 152 | 75 | 100 | 31 | ||||
